The ANTLR mega tutorial

The ANTLR mega tutorialParsers are powerful tools, and using ANTLR you could write all sort of parsers usable from many different languages.

In this complete tutorial we are going to:

  • explain the basis: what a parser is, what it can be used for
  • see how to setup ANTLR to be used from Javascript, Python, Java and C#
  • discuss how to test your parser
  • present the most advanced and useful features present in ANTLR: you will learn all you need to parse all possible languages
  • show tons of examples

Maybe you have read some tutorial that was too complicated or so partial that seemed to assume that you already know how to use a parser. This is not that kind of tutorial. We just expect you to know how to code and how to use a text editor or an IDE. That’s it.

At the end of this tutorial:

  • you will be able to write a parser to recognize different formats and languages
  • you will be able to create all the rules you need to build a lexer and a parser
  • you will know how to deal with the common problems you will encounter
  • you will understand errors and you will know how to avoid them by testing your grammar.

In other words, we will start from the very beginning and when we reach the end you will have learned all you could possible need to learn about ANTLR.

ANTLR Mega Tutorial Giant List of Content

ANTLR Mega Tutorial Giant List of Content

What is ANTLR?

ANTLR is a parser generator, a tool that helps you to create parsers. A parser takes a piece of text and transform it in an organized structure, such as an Abstract Syntax Tree (AST). You can think of the AST as a story describing the content of the code or also as its logical representation created by putting together the various pieces.

An abstract syntax tree for the Euclidean algorithm

Graphical representation of an AST for the Euclidean algorithm

What you need to do to get an AST:

  1. define a lexer and parser grammar
  2. invoke ANTLR: it will generate a lexer and a parser in your target language (e.g., Java, Python, C#, Javascript)
  3. use the generated lexer and parser: you invoke them passing the code to recognize and they return to you an AST

So you need to start by defining a lexer and parser grammar for the thing that you are analyzing. Usually the “thing” is a language, but it could also be a data format, a diagram, or any kind of structure that is represented with text.

Aren’t regular expressions enough?

If you are the typical programmer you may ask yourself why can’t I use a regular expression? A regular expression is quite useful, such as when you want to find a number in a string of text, but it also has many limitations.

The most obvious is the lack of recursion: you can’t find a (regular) expression inside another one, unless you code it by hand for each level. Something that quickly became unmaintainable. But the larger problem is that it’s not really scalable: if you are going to put together even just a few regular expressions, you are going to create a fragile mess that would be hard to maintain.

It’s not that easy to use regular expressions

Have you ever tried parsing HTML with a regular expression? It’s a terrible idea, for one you risk summoning Cthulhu, but more importantly it doesn’t really work. You don’t believe me? Let’s see, you want to find the elements of a table, so you try a regular exprdatession like this one: <table>(.*?)</table>. Brilliant! You did it! Except somebody adds attributes to their table, such as style or id. It doesn’t matter, you do this <table.*?>(.*?)</table>, but you actually cared about the data inside the table, so you then need to parse tr and td, but they are full of tags.

So you need to eliminate that, too. And somebody dares even to use comments like <!— my comment &gtl—>. Comments can be used everywhere, and that is not easy to treat with your regular expression. Is it?

So you forbid the internet to use comments in HTML: problem solved.

Or alternatively you use ANTLR, whatever seems simpler to you.

ANTLR vs writing your own parser by hand

Okay, you are convinced, you need a parser, but why to use a parser generator like ANTLR instead of building your own?

The main advantage of ANTLR is productivity

If you actually have to work with a parser all the time, because your language, or format, is evolving, you need to be able to keep the pace, something you can’t do if you have to deal with the details of implementing a parser. Since you are not parsing for parsing’s sake, you must have the chance to concentrate on accomplishing your goals. And ANTLR make it much easier to do that, rapidly and cleanly.

As second thing, once you defined your grammars you can ask ANTLR to generate multiple parsers in different languages. For example you can get a parser in C# and one in Javascript to parse the same language in a desktop application and in a web application.

Some people argue that writing a parser by hand you can make it faster and you can produce better error messages. There is some truth in this, but in my experience parsers generated by ANTLR are always fast enough. You can tweak them and improve both performance and error handling by working on your grammar, if you really need to. And you can do that once you are happy with your grammar.

Table of Contents or ok, I am convinced, show me what you got

Two small notes:

  • in the companion repository of this tutorial you are going to find all the code with testing, even where we don’t see it in the article
  • the examples will be in different languages, but the knowledge would be generally applicable to any language

Setup

  1. Setup ANTLR
  2. Javascript Setup
  3. Python Setup
  4. Java Setup
  5. C# Setup

Beginner

  1. Lexers and Parsers
  2. Creating a Grammar
  3. Designing a Data Format
  4. Lexer Rules
  5. Parser Rules
  6. Mistakes and Adjustments

Mid-Level

  1. Setting Up the Chat Project in Javascript
  2. Antlr.js
  3. HtmlChatListener.js
  4. Working with a Listener
  5. Solving Ambiguities with Semantic Predicates
  6. Continuing the Chat in Python
  7. The Python Way of Working with a Listener
  8. Testing with Python
  9. Parsing Markup
  10. Lexical Modes
  11. Parser Grammars

Advanced

  1. The Markup Project in Java
  2. The Main App.java
  3. Transforming Code with ANTLR
  4. Joy and Pain of Transforming Code
  5. Advanced Testing
  6. Dealing with Expressions
  7. Parsing Spreadsheets
  8. The Spreadsheet Project in C#
  9. Excel is Doomed
  10. Testing Everything

Final Remarks

  1. Tips and Tricks
  2. Conclusions

Setup

In this section we prepare our development environment to work with ANTLR: the parser generator tool, the supporting tools and the runtimes for each language.

1. Setup ANTLR

ANTLR is actually made up of two main parts: the tool, used to generate the lexer and parser, and the runtime, needed to run them.

The tool will be needed just by you, the language engineer, while the runtime will be included in the final software using your language.

The tool is always the same no matter which language you are targeting: it’s a Java program that you need on your development machine. While the runtime is different for every language and must be available both to the developer and to the user.

The only requirement for the tool is that you have installed at least Java 1.7. To install the Java program you need to download the last version from the official site, which at the moment is:

Instructions

  1. copy the downloaded tool where you usually put third-party java libraries (ex. /usr/local/lib or C:\Program Files\Java\lib)
  2. add the tool to your CLASSPATH. Add it to your startup script (ex. .bash_profile)
  3. (optional) add also aliases to your startup script to simplify the usage of ANTLR

Executing the instructions on Linux/Mac OS

Executing the instructions on Windows

Typical Workflow

When you use ANTLR you start by writing a grammar, a file with extension .g4 which contains the rules of the language that you are analyzing. You then use the antlr4 program to generate the files that your program will actually use, such as the lexer and the parser.

There are a couple of important options you can specify when running antlr4.

First, you can specify the target language, to generate a parser in Python or JavaScript or any other target different from Java (which is the default one). The other ones are used to generate visitor and listener (don’t worry if you don’t know what these are, we are going to explain it later).

By default only the listener is generated, so to create the visitor you use the -visitor command line option, and -no-listener if you don’t want to generate the listener. There are also the opposite options, -no-visitor and -listener, but they are the default values.

You can optiofi test your grammar using a little utility named TestRig (although, as we have seen, it’s usually aliased to grun).

The filename(s) are optional and you can instead analyze the input that you type on the console.

If you want to use the testing tool you need to generate a Java parser, even if your program is written in another language. This can be done just by selecting a different option with antlr4.

Grun is useful when testing manually the first draft of your grammar. As it becomes more stable you may want to relay on automated tests (we will see how to write them).

Grun also has a few useful options: -tokens, to shows the tokens detected,  -gui to generate an image of the AST.

2. Javascript Setup

You can put your grammars in the same folder as your Javascript files. The file containing the grammar must have the same name of the grammar, which must be declared at the top of the file.

In the following example the name is Chat and the file is Chat.g4.

We can create the corresponding Javascript parser simply by specifying the correct option with the ANTLR4 Java program.

Notice that the option is case-sensitive, so pay attention to the uppercase ‘S’. If you make a mistake you will receive a message like the following.

ANTLR can be used both with node.js and in the browser. For the browser you need to use webpack or require.js. If you don’t know how to use either of the two you can look at the official documentation for some help or read this tutorial on antlr in the web. We are going to use node.js, for which you can install the ANTLR runtime simply by using the following standard command.

3. Python Setup

When you have a grammar you put that in the same folder as your Python files. The file must have the same name of the grammar, which must be declared at the top of the file. In the following example the name is Chat and the file is Chat.g4.

We can create the corresponding Python parser simply by specifying the correct option with the ANTLR4 Java program. For Python, you also need to pay attention to the version of Python, 2 or 3.

The runtime is available from PyPi so you just can install it using pio.

Again, you just have to remember to specify the proper python version.

4. Java Setup

To setup our Java project using ANTLR you can do things manually. Or you can be a civilized person and use Gradle or Maven.

Also, you can look in ANTLR plugins for your IDE.

4.1 Java Setup using Gradle

This is how I typically setup my Gradle project.

I use a Gradle plugin to invoke ANTLR and I also use the IDEA plugin to generate the configuration for IntelliJ IDEA.

I put my grammars under src/main/antlr/ and the gradle configuration make sure they are generated in the directory corresponding to their package. For example, if I want the parser to be in the package me.tomassetti.mylanguage it has to be generated into generated-src/antlr/main/me/tomassetti/mylanguage.

At this point I can simply run:

And I get my lexer & parser generated from my grammar(s).

Then I can also run:

And I have an IDEA Project ready to be opened.

4.2 Java Setup using Maven

First of all we are going to specify in our POM that we need antlr4-runtime as a dependency. We will also use a Maven plugin to run ANTLR through Maven.

We can also specify if we ANTLR to generate visitors or listeners. To do that we define a couple of corresponding properties.

Now you have to put the *.g4 files of your grammar under src/main/antlr4/me/tomassetti/examples/MarkupParser.

Once you have written your grammars you just run mvn package and all the magic happens: ANTLR is invoked, it generates the lexer and the parser and those are compiled together with the rest of your code.

If you have never used Maven you can look at the official ANTLR documentation for the Java target or also the Maven website to get you started.

There is a clear advantage in using Java for developing ANTLR grammars: there are plugins for several IDEs and it’s the language that the main developer of the tool actually works on. So they are tools, like the org.antlr.v4.gui.TestRig, that can be easily integrated in you workflow and are useful if you want to easily visualize the AST of an input.

5. C# Setup

There is support for .NET Framework and Mono 3.5, but there is no support for .NET core. We are going to use Visual Studio to create our ANTLR project, because there is a nice extension for Visual Studio created by the same author of the C# target, called ANTLR Language Support. You can install it by going in Tools -> Extensions and Updates. This extension will automatically generate parser, lexer and visitor/listener when you build your project.

Furthermore, the extension will allow you to create a new grammar file, using the well known menu to add a new item. Last, but not least, you can setup the options to generate listener/visitor right in the properties of each grammar file.

Alternatively, if you prefer to use an editor, you need to use the usual Java tool to generate everything. You can do that just by indicating the right language. In this example the grammar is called “Spreadsheet”.

Notice that the ‘S’ in CSharp is uppercase.

You still need the ANTLR4 runtime for your project, and you can install it with the good ol’ nuget.

Beginner

In this section we lay the foundation you need to use ANTLR: what lexer and parsers are, the syntax to define them in a grammar and the strategies you can use to create one. We also see the first examples to show how to use what you have learned.  You can come back to this section if you don’t remember how ANTLR works.

6. Lexers and Parsers

Before looking into parsers, we need to first to look into lexers, also known as tokenizers. They are basically the first stepping stone toward a parser, and of course ANTLR allows you to build them too. A lexer takes the individual characters and transforms them in tokens, the atoms that the parser uses to create the logical structure.

Imagine this process applied to a natural language such as English. You are reading the single characters, putting them together until they make a word, and then you combine the different words to form a sentence.

Let’s look at the following example and imagine that we are trying to parse a mathematical operation.

The lexer scans the text and find ‘4’, ‘3’, ‘7’ and then the space ‘ ‘. So it knows that the first characters actually represent a number. Then it finds a ‘+’ symbol, so it knows that it represents an operator, and lastly it finds another number.How the input stream is analyzed

How does it knows that? Because we tell it.

This is not a complete grammar, but we can already see that lexer rules are all uppercase, while parser rules are all lowercase. Technically the rule about case applies only to the first character of their names, but usually they are all uppercase or lowercase for clarity.

Rules are typically written in this order: first the parser rules and then the lexer ones, although logically they are applied in the opposite order. It’s also important to remember that lexer rules are analyzed in the order that they appear, and they can be ambiguous.

The typical example is the identifier: in many programming language it can be any string of letters, but certain combinations, such as “class” or “function” are forbidden because they indicate a class or a function. So the order of the rules solves the ambiguity by using the first match and that’s why the tokens identifying keywords such as class or function are defined first, while the one for the identifier is put last.

The basic syntax of a rule is easy: there is a name, a colon, the definition of the rule and a terminating semicolon

The definition of NUMBER contains a typical range of digits and a ‘+’ symbol to indicate that one or more matches are allowed. These are all very typical indications with which I assume you are familiar with, if not, you can read more about the syntax of regular expressions.

The most interesting part is at the end, the lexer rule that defines the WHITESPACE token. It’s interesting because it shows how to indicate to ANTLR to ignore something. Consider how ignoring whitespace simplify parser rules: if we couldn’t say to ignore WHITESPACE we would have to include it between every single subrule of the parser, to let the user puts spaces where he wants. Like this:

And the same typically applies to comments: they can appear everywhere and we do not want to handle them specifically in every single piece of our grammar so we just ignore them (at least while parsing) .

7. Creating a Grammar

Now that we have seen the basic syntax of a rule, we can take a look at the two different approaches to define a grammar: top-down and bottom-up.

Top-down approach

This approach consist in starting from the general organization of a file written in your language.

What are the main section of a file? What is their order? What is contained in each section?

For example a Java file can be divided in three sections:

  • package declaration
  • imports
  • type definitions

This approach works best when you already know the language or format that you are designing a grammar for. It is probably the strategy preferred by people with a good theoretical background or people who prefer to start with “the big plan”.

When using this approach you start by defining the rule representing the whole file. It will probably include other rules, to represent the main sections. You then define those rules and you move from the most general, abstract rules to the low-level, practical ones.

Bottom-up approach

The bottom-up approach consists in focusing in the small elements first: defining how the tokens are captured, how the basic expressions are defined and so on. Then we move to higher level constructs until we define the rule representing the whole file.

I personally prefer to start from the bottom, the basic items, that are analyzed with the lexer. And then you grow naturally from there to the structure, that is dealt with the parser. This approach permits to focus on a small piece of the grammar, build thests for that, ensure it works as expected and then move on to the next bit.

This approach mimic the way we learn. Furthermore, there is the advantage of starting with real code that is actually quite common among many languages. In fact, most languages have things like identifiers, comments, whitespace, etc. Obviously you might have to tweak something, for example a comment in HTML is functionally the same as a comment in C#, but it has different delimiters.

The disadvantage of a bottom-up approach rests on the fact that the parser is the thing you actually cares about. You weren’t asked to build a lexer, you were asked to build a parser, that could provide a specific functionality. So by starting on the last part, the lexer, you might end up doing some refactoring, if you don’t already know how the rest of the program will work.

8. Designing a Data Format

Designing a grammar for a new language is difficult. You have to create a language simple and intuitive to the user, but also unambiguous to make the grammar manageable. It must be concise, clear, natural and it shouldn’t get in the way of the user.

So we are starting with something limited: a grammar for a simple chat program.

Let’s start with a better description of our objective:

  • there are not going to be paragraphs, and thus we can use newlines as separators between the messages
  • we want to allow emoticons, mentions and links. We are not going to support HTML tags
  • since our chat is going to be for annoying teenagers, we want to allow users an easy way to SHOUT and to format the color of the text.

Finally teenagers could shout, and all in pink. What a time to be alive.

9. Lexer Rules

We start with defining lexer rules for our chat language. Remember that lexer rules actually are at the end of the files.

In this example we use rules fragments: they are reusable building blocks for lexer rules. You define them and then you refer to them in lexer rule. If you define them but do not include them in lexer rules they have simply no effect.

We define a fragment for the letters we want to use in keywords. Why is that? because we want to support case-insensitive keywords. Other than to avoid repetition of the case of characters, they are also used when dealing with floating numbers. To avoid repeating digits, before and after the dot/comma. Such as in the following example.

The TEXT token shows how to capture everything, except for the characters the follows the tilde (‘~’). We are excluding the closing square bracket ‘]’, but since it is a character used to identify the end of a group of characters, we have to escape it by prefixing it with a backslash ‘\’.

The newlines rule is formulated that way because there are actually different ways in which operating systems indicate a newline, some include a carriage return ('\r') others a newline ('\n') character, or a combination of the two.

10. Parser Rules

We continue with parser rules, which are the rules with which our program will interact most directly.

The first interesting part is message, not so much for what it contains, but the structure it represents. We are saying that a message could be anything of the listed rules in any order. This is a simple way to solve the problem of dealing with whitespace without repeating it every time. Since we, as users, find whitespace irrelevant we see something like WORD WORD mention, but the parser actually sees WORD WHITESPACE WORD WHITESPACE mention WHITESPACE.

Another way of dealing with whitespace, when you can’t get rid of it, is more advanced: lexical modes. Basically it allows you to specify two lexer parts: one for the structured part, the other for simple text. This is useful for parsing things like XML or HTML. We are going to show it later.

The command rule it’s obvious, you have just to notice that you cannot have a space between the two options for command and the colon, but you need one WHITESPACE after. The emoticon rule shows another notation to indicate multiple choices, you can use the pipe character ‘|’ without the parenthesis. We support only two emoticons, happy and sad, with or without the middle line.

Something that could be considered a bug, or a poor implementation, is the link rule, as we already said, in fact, TEXT capture everything apart from certain special characters. You may want to only allows WORD and WHITESPACE, inside the parentheses, or to force a correct format for a link, inside the square brackets. On the other hand, this allows the user to make a mistake in writing the link without making the parser complain.

You have to remember that the parser cannot check for semantics

For instance, it cannot know if the WORD indicating the color actually represents a valid color. That is to say, it doesn’t know that it’s wrong to use “dog”, but it’s right to use “red”. This must be checked by the logic of the program, that can access which colors are available. You have to find the right balance of dividing enforcement between the grammar and your own code.

The parser should only check the syntax. So the rule of thumb is that when in doubt you let the parser pass the content up to your program. Then, in your program, you check the semantics and make sure that the rule actually have a proper meaning.

Let’s look at the rule color: it can include a message,  and it itself can be part of message; this ambiguity will be solved by the context in which is used.

11. Mistakes and Adjustments

Before trying our new grammar we have to add a name for it, at the beginning of the file. The name must be the same of the file, which should have the .g4 extension.

You can find how to install everything, for your platform, in the official documentation. After everything is installed, we create the grammar, compile the generate Java code and then we run the testing tool.

Okay, it doesn’t work. Why is it expecting WORD? It’s right there! Let’s try to find out, using the option -tokens to make it shows the tokens it recognizes.

So it only sees the TEXT token. But we put it at the end of the grammar, what happens? The problem is that it always try to match the largest possible token. And all this text is a valid TEXT token. How we solve this problem? There are many ways, the first, of course, is just getting rid of that token. But for now we are going to see the second easiest.

We have changed the problematic token to make it include a preceding parenthesis or square bracket. Note that this isn’t exactly the same thing, because it would allow two series of parenthesis or square brackets. But it is a first step and we are learning here, after all.

Let’s check if it works:

Using the option -gui we can also have a nice, and easier to understand, graphical representation.

ANTLR4 Parse Tree

The dot in mid air represents whitespace.

This works, but it isn’t very smart or nice, or organized. But don’t worry, later we are going to see a better way. One positive aspect of this solution is that it allows to show another trick.

This is an equivalent formulation of the token TEXT: the ‘.’ matches any character, ‘*’ says that the preceding match can be repeated any time, ‘?’ indicate that the previous match is non-greedy. That is to say the previous subrule matches everything except what follows it, allowing to match the closing parenthesis or square bracket.

Mid-Level

In this section we see how to use ANTLR in your programs, the libraries and functions you need to use, how to tests your parsers, and the like. We see what is and how to use a listener. We also build up on our knowledge of the basics, by looking at more advanced concepts, such as semantic predicates. While our projects are mainly in Javascript and Python, the concept are generally applicable to every language. You can come back to this section when you need to remember how to get your project organized.

12. Setting Up the Chat Project with Javascript

In the previous sections we have seen how to build a grammar for a chat program , piece by piece. Let’s now copy that grammar we just created in the same folder of our Javascript files.

We can create the corresponding Javascript parser simply by specifying the correct option with the ANTLR4 Java program.

Now you will find some new files in the folder, with names such as ChatLexer.js, ChatParser.js and there are also *.tokens files, none of which contains anything interesting for us, unless you want to understand the inner workings of ANTLR.

The file you want to look at is ChatListener.js,  you are not going to modify anything in it, but it contains methods and functions that we will override with our own listener. We are not going to modify it, because changes would be overwritten every time the grammar is regenerated.

Looking into it you can see several enter/exit functions, a pair for each of our parser rules. These functions will be invoked when a piece of code matching the rule will be encountered. This is the default implementation of the listener that allows you to just override the functions that you need, on your derived listener, and leave the rest to be.

The alternative to creating a Listener is creating a Visitor. The main differences are that you can’t neither control the flow of a listener nor returning anything from its functions, while you can do both of them with a visitor. So if you need to control how the nodes of the AST are entered, or to gather information from several of them, you probably want to use a visitor. This is useful, for example, with code generation, where some information that is needed to create new source code is spread around many parts. Both the listener and the visitor use depth-first search.

A depth-first search means that when a node will be accessed its children will be accessed, and if one the children nodes had its own children they will be accessed before continuing on with the other children of the first node. The following image will make it simpler to understand the concept.

Depth-first search

So in the case of a listener an enter event will be fired at the first encounter with the node and a exit one will be fired after after having exited all of its children. In the following image you can see the example of what functions will be fired when a listener would met a line node (for simplicity only the functions related to line are shown).

ANTLR Listener Example

With a standard visitor the behavior will be analogous except, of course, that only a single visit event will be fired for every single node. In the following image you can see the example of what function will be fired when a visitor would met a line node (for simplicity only the function related to line is shown).

ANTLR Visitor Example

Remember that this is true for the default implementation of a visitor and it’s done by returning the children of each node in every function. If you override a method of the visitor it’s your responsibility to make it continuing the journey or stop it right there.

13. Antlr.js

It is finally time to see how a typical ANTLR program looks.

At the beginning of the main file we import (using require) the necessary libraries and file, antlr4 (the runtime) and our generated parser, plus the listener that we are going to see later.

For simplicity we get the input from a string, while in a real scenario it would come from an editor.

Lines 16-19 shows the foundation of every ANTLR program: you create the stream of chars from the input, you give it to the lexer and it transforms them in tokens, that are then interpreted by the parser.

It’s useful to take a moment to reflect on this: the lexer works on the characters of the input, a copy of the input to be precise, while the parser works on the tokens generated by the parser. The lexer doesn’t work on the input directly, and the parser doesn’t even see the characters.

This is important to remember in case you need to do something advanced like manipulating the input. In this case the input is a string, but, of course, it could be any stream of content.

The line 20 is redundant, since the option already default to true, but that could change in future versions of the runtimes, so you are better off by specifying it.

Then, on line 21, we set the root node of the tree as a chat rule. You want to invoke the parser specifying a rule which typically is the first rule. However you can actually invoke any rule directly, like color.

Once we get the AST from the parser typically we want to process it using a listener or a visitor. In this case we specify a listener. Our particular listener take a parameter: the response object. We want to use it to put some text in the response to send to the user. After setting the listener up, we finally walk the tree with our listener.

14. HtmlChatListener.js

We continue by looking at the listener of our Chat project.

After the requires function calls we make our HtmlChatListener to extend ChatListener. The interesting stuff starts at line 17.

The ctx argument is an instance of a specific class context for the node that we are entering/exiting. So for enterName is NameContext, for exitEmoticon is EmoticonContext, etc. This specific context will have the proper elements for the rule, that would make possible to easily access the respective tokens and subrules. For example, NameContext will contain fields like WORD() and WHITESPACE(); CommandContext will contain fields like WHITESPACE(), SAYS() and SHOUTS().

These functions, enter* and exit*, are called by the walker everytime the corresponding nodes are entered or exited while it’s traversing the AST that represents the program newline. A listener allows you to execute some code, but it’s important to remember that you can’t stop the execution of the walker and the execution of the functions.

On line 18, we start by printing a strong tag because we want the name to be bold, then on exitName we take the text from the token WORD and close the tag. Note that we ignore the WHITESPACE token, nothing says that we have to show everything. In this case we could have done everything either on the enter or exit function.

On the function exitEmoticon we simply transform the emoticon text in an emoji character. We get the text of the whole rule because there are no tokens defined for this parser rule. On enterCommand, instead there could be any of two tokens SAYS or SHOUTS, so we check which one is defined. And then we alter the following text, by transforming in uppercase, if it’s a SHOUT. Note that we close the p tag at the exit of the line rule, because the command, semantically speaking, alter all the text of the message.

All we have to do now is launching node, with nodejs antlr.js, and point our browser at its address, usually at http://localhost:1337/ and we will be greeted with the following image.

ANTLR4 Javascript So all is good, we just have to add all the different listeners to handle the rest of the language. Let’s start with color and message.

15. Working with a Listener

We have seen how to start defining a listener. Now let’s get serious on see how to evolve in a complete, robust listener. Let’s start by adding support for color and checking the results of our hard work.

ANTLR4 Javascript ouput

Except that it doesn’t work. Or maybe it works too much: we are writing some part of message twice (“this will work”): first when we check the specific nodes, children of message, and then at the end.

Luckily with Javascript we can dynamically alter objects, so we can take advantage of this fact to change the *Context object themselves.

Only the modified parts are shown in the snippet above. We add a text field to every node that transforms its text, and then at the exit of every message we print the text if it’s the primary message, the one that is directly child of the line rule. If it’s a message, that is also a child of color, we add the text field to the node we are exiting and let color print it. We check this on line 30, where we look at the parent node to see if it’s an instance of the object LineContext. This is also further evidence of how each ctx argument corresponds to the proper type.

Between lines 23 and 27 we can see another field of every node of the generated tree: children, which obviously it contains the children node. You can observe that if a field text exists we add it to the proper variable, otherwise we use the usual function to get the text of the node.

16. Solving Ambiguities with Semantic Predicates

So far we have seen how to build a parser for a chat language in Javascript. Let’s continue working on this grammar but switch to python. Remember that all code is available in the repository. Before that, we have to solve an annoying problem: the TEXT token. The solution  we have  is terrible, and furthermore, if we tried to get the text of the token we would have to trim the edges, parentheses or square brackets. So what can we do?

We can use a particular feature of ANTLR called semantic predicates. As the name implies they are expressions that produce a boolean value. They selectively enable or disable the following rule and thus permit to solve ambiguities. Another reason that they could be used is to support different version of the same language, for instance a version with a new construct or an old without it.

Technically they are part of the larger group of actions, that allows to embed arbitrary code into the grammar. The downside is that the grammar is no more language independent, since the code in the action must be valid for the target language. For this reason, usually it’s considered a good idea to only use semantic predicates, when they can’t be avoided, and leave most of the code to the visitor/listener.

We restored link to its original formulation, but we added a semantic predicate to the TEXT token, written inside curly brackets and followed by a question mark. We use self._input.LA(-1) to check the character before the current one, if this character is a square bracket or the open parenthesis, we activate the TEXT token. It’s important to repeat that this must be valid code in our target language, it’s going to end up in the generated Lexer or Parser, in our case in ChatLexer.py.

This matters not just for the syntax itself, but also because different targets might have different fields or methods, for instance LA returns an int in python, so we have to convert the char to a int.

Let’s look at the equivalent form in other languages.

If you want to test for the preceding token, you can use the _input.LT(-1,)but you can only do that for parser rules. For example, if you want to enable the mention rule only if preceded by a WHITESPACE token.

17. Continuing the Chat in Python

Before seeing the Python example, we must modify our grammar and put the TEXT token before the WORD one. Otherwise ANTLR might assign the incorrect token, in cases where the characters between parentheses or brackets are all valid for WORD, for instance if it where [this](link).

Using ANTLR in python is not more difficult than with any other platform, you just need to pay attention to the version of Python, 2 or 3.

And that’s it. So when you have run the command, inside the directory of your python project, there will be a newly generated parser and a lexer. You may find interesting to look at ChatLexer.py and in particular the function TEXT_sempred (sempred stands for semantic predicate).

You can see our predicate right in the code. This also means that you have to check that the correct libraries, for the functions used in the predicate, are available to the lexer.

18. The Python Way of Working with a Listener

The main file of a Python project is very similar to a Javascript one, mutatis mutandis of course. That is to say we have to adapt libraries and functions to the proper version for a different language.

We have also changed the input and output to become files, this avoid the need to launch a server in Python or the problem of using characters that are not supported in the terminal.

Apart from lines 35-36, where we introduce support for links, there is nothing new. Though you might notice that Python syntax is cleaner and, while having dynamic typing, it is not loosely typed as Javascript. The different types of *Context objects are explicitly written out. If only Python tools were as easy to use as the language itself. But of course we cannot just fly over python like this, so we also introduce testing.

19. Testing with Python

While Visual Studio Code have a very nice extension for Python, that also supports unit testing, we are going to use the command line for the sake of compatibility.

That’s how you run the tests, but before that we have to write them. Actually, even before that, we have to write an ErrorListener to manage errors that we could find. While we could simply read the text outputted by the default error listener, there is an advantage in using our own implementation, namely that we can control more easily what happens.

Our class derives from ErrorListener and we simply have to implement syntaxError. Although we also add a property symbol to easily check which symbol might have caused an error.

The setup method is used to ensure that everything is properly set; on lines 19-21 we setup also our ChatErrorListener, but first we remove the default one, otherwise it would still output errors on the standard output. We are listening to errors in the parser, but we could also catch errors generated by the lexer. It depends on what you want to test. You may want to check both.

The two proper test methods checks for a valid and an invalid name. The checks are linked to the property symbol, that we have previously defined, if it’s empty everything is fine, otherwise it contains the symbol that created the error. Notice that on line 28, there is a space at the end of the string, because we have defined the rule name to end with a WHITESPACE token.

20. Parsing Markup

ANTLR can parse many things, including binary data, in that case tokens are made up of non printable characters. But a more common problem is parsing markup languages such as XML or HTML. Markup is also a useful format to adopt for your own creations, because it allows to mix unstructured text content with structured annotations. They fundamentally represent a form of smart document, containing both text and structured data. The technical term that describe them is island languages. This type is not restricted to include only markup, and sometimes it’s a matter of perspective.

For example, you may have to build a parser that ignores preprocessor directives. In that case, you have to find a way to distinguish proper code from directives, which obeys different rules.

In any case, the problem for parsing such languages is that there is a lot of text that we don’t actually have to parse, but we cannot ignore or discard, because the text contain useful information for the user and it is a structural part of the document. The solution is lexical modes, a way to parse structured content inside a larger sea of free text.

21. Lexical Modes

We are going to see how to use lexical modes, by starting with a new grammar.

Looking at the first line you could notice a difference: we are defining a lexer grammar, instead of the usual (combined) grammar. You simply can’t define a lexical mode together with a parser grammar. You can use lexical modes only in a lexer grammar, not in a combined grammar. The rest is not suprising, as you can see, we are defining a sort of BBCode markup, with tags delimited by square brackets.

On lines 3, 7 and 9 you will find basically all that you need to know about lexical modes. You define one or more tokens that can delimit the different modes and activate them.

The default mode is already implicitly defined, if you need to define yours you simply use mode followed by a name. Other than for markup languages, lexical modes are typically used to deal with string interpolation. When a string literal can contain more than simple text, but things like arbitrary expressions.

When we used a combined grammar we could define tokens implicitly: when in a parser rule we used a string like ‘=’ that is what we did. Now that we are using separate lexer and parser grammars we cannot do that. That means that every single token has to be defined explicitly. So we have definitions like SLASH or EQUALS which typically could be just be directly used in a parser rule. The concept is simple: in the lexer grammar we need to define all tokens, because they cannot be defined later in the parser grammar.

22. Parser Grammars

We look at the other side of a lexer grammar, so to speak.

On the first line we define a parser grammar. Since the tokens we need are defined in the lexer grammar, we need to use an option to say to ANTLR where it can find them. This is not necessary in combined grammars, since the tokens are defined in the same file.

There are many other options available, in the documentation.

There is almost nothing else to add, except that we define a content rule so that we can manage more easily the text that we find later in the program.

I just want to say that, as you can see, we don’t need to explicitly use the tokens everytime (es. SLASH), but instead we can use the corresponding text (es. ‘/’).

ANTLR will automatically transform the text in the corresponding token, but this can happen only if they are already defined. In short, it is as if we had written:

But we could not have used the implicit way, if we hadn’t already explicitly defined them in the lexer grammar. Another way to look at this is: when we define a combined grammar ANTLR defines for use all the tokens, that we have not explicitly defined ourselves. When we need to use a separate lexer and a parser grammar, we have to define explicitly every token ourselves. Once we have done that, we can use them in every way we want.

Before moving to actual Java code, let’s see the AST for a sample input.

Sample AST of the Markup parser

You can easily notice that the element rule is sort of transparent: where you would expect to find it there is always going to be a tag or content. So why did we define it? There are two advantages: avoid repetition in our grammar and simplify managing the results of the parsing. We avoid repetition because if we did not have the element rule we should repeat (content|tag) everywhere it is used. What if one day we add a new type of element? In addition to that it simplify the processing of the AST because it makes both the node represent tag and content extend a comment ancestor.

Advanced

In this section we deepen our understanding of ANTLR. We will look at more complex examples and situations we may have to handle in our parsing adventures. We will learn how to perform more adavanced testing, to catch more bugs and ensure a better quality for our code. We will see what a visitor is and how to use it. Finally, we will see how to deal with expressions and the complexity they bring.

You can come back to this section when you need to deal with complex parsing problems.

23. The Markup Project in Java

You can follow the instructions in Java Setup or just copy the antlr-java folder of the companion repository. Once the file pom.xml is properly configured, this is how you build and execute the application.

As you can see, it isn’t any different from any typical Maven project, although it’s indeed more complicated that a typical Javascript or Python project. Of course, if you use an IDE you don’t need to do anything different from your typical workflow.

24. The Main App.java

We are going to see how to write a typical ANTLR application in Java.

At this point the main java file should not come as a surprise, the only new development is the visitor. Of course, there are the obvious little differences in the names of the ANTLR classes and such. This time we are building a visitor, whose main advantage is the chance to control the flow of the program. While we are still dealing with text, we don’t want to display it, we want to transform it from pseudo-BBCode to pseudo-Markdown.

25. Transforming Code with ANTLR

The first issue to deal with our translation from pseudo-BBCode to pseudo-Markdown is a design decision. Our two languages are different and frankly neither of the two original one is that well designed.

BBCode was created as a safety precaution, to make possible to disallow the use of HTML but giove some of its power to users. Markdown was created to be an easy to read and write format, that could be translated into HTML. So they both mimic HTML, and you can actually use HTML in a Markdown document. Let’s start to look into how messy would be a real conversion.

The first version of our visitor prints all the text and ignore all the tags.

You can see how to control the flow, either by calling visitChildren, or any other visit* function, and deciding what to return. We just need to override the methods that we want to change. Otherwise, the default implementation would just do like visitContent, on line 23, it will visit the children nodes and allows the visitor to continue. Just like for a listener, the argument is the proper context type. If you want to stop the visitor just return null as on line 15.

26. Joy and Pain of Transforming Code

Transforming code, even at a very simple level, comes with some complications. Let’s start easy with some basic visitor methods.

Before looking at the main method, let’s look at the supporting ones. Foremost we have changed visitContent by making it return its text instead of printing it. Second, we have overridden the visitElement so that it prints the text of its child, but only if it’s a top element, and not inside a tag. In both cases, it achieve this by calling the proper visit* method. It knows which one to call because it checks if it actually has a tag or content node.

VisitTag contains more code than every other method, because it can also contain other elements, including other tags that have to be managed themselves, and thus they cannot be simply printed. We save the content of the ID on line 5, of course we don’t need to check that the corresponding end tag matches, because the parser will ensure that, as long as the input is well formed.

The first complication starts with at lines 14-15: as it often happens when transforming a language in a different one, there isn’t a perfect correspondence between the two. While BBCode tries to be a smarter and safer replacement for HTML, Markdown want to accomplish the same objective of HTML, to create a structured document. So BBCode has an underline tag, while Markdown does not.

So we have to make a decision

Do we want to discard the information, or directly print HTML, or something else? We choose something else and instead convert the underline to an italic. That might seem completely arbitrary, and indeed there is an element of choice in this decision. But the conversion forces us to lose some information, and both are used for emphasis, so we choose the closer thing in the new language.

The following case, on lines 18-22, force us to make another choice. We can’t maintain the information about the author of the quote in a structured way, so we choose to print the information in a way that will make sense to a human reader.

On lines 28-34 we do our “magic”: we visit the children and gather their text, then we close with the endDelimiter. Finally we return the text that we have created.

That’s how the visitor works

  1. every top element visit each child
    • if it’s a content node, it directly returns the text
    • if it’s a tag, it setups the correct delimiters and then it checks its children. It repeats step 2 for each children and then it returns the gathered text
  2. it prints the returned text

It’s obviously a simple example, but it show how you can have great freedom in managing the visitor once you have launched it. Together with the patterns that we have seen at the beginning of this section you can see all of the options: to return null to stop the visit, to return children to continue, to return something to perform an action ordered at an higher level of the tree.

27. Advanced Testing

The use of lexical modes permit to handle the parsing of island languages, but it complicates testing.

We are not going to show MarkupErrorListener.java because w edid not changed it; if you need you can see it on the repository.

You can run the tests by using the following command.

Now we are going to look at the tests code. We are skipping the setup part, because that also is obvious, we just copy the process seen on the main file, but we simply add our error listener to intercept the errors.

The first two methods are exactly as before, we simply check that there are no errors, or that there is the correct one because the input itself is erroneous. On lines 30-32 things start to get interesting: the issue is that by testing the rules one by one we don’t give the chance to the parser to switch automatically to the correct mode. So it remains always on the DEFAULT_MODE, which in our case makes everything looks like TEXT. This obviously makes the correct parsing of an attribute impossible.

The same lines shows also how you can check the current mode that you are in, and the exact type of the tokens that are found by the parser, which we use to confirm that indeed all is wrong in this case.

While we could use a string of text to trigger the correct mode, each time, that would make testing intertwined with several pieces of code, which is a no-no. So the solution is seen on line 39: we trigger the correct mode manually. Once you have done that, you can see that our attribute is recognized correctly.

28. Dealing with Expressions

So far we have written simple parser rules, now we are going to see one of the most challenging parts in analyzing a real (programming) language: expressions. While rules for statements are usually larger they are quite simple to deal with: you just need to write a rule that encapsulate the structure with the all the different optional parts. For instance a for statement can include all other kind of statements, but we can simply include them with something like statement*. An expression, instead, can be combined in many different ways.

An expression usually contains other expressions. For example the typical binary expression is composed by an expression on the left, an operator in the middle and another expression on the right. This can lead to ambiguities. Think, for example, at the expression 5 + 3 * 2, for ANTLR this expression is ambiguous because there are two ways to parse it. It could either parse it as 5 + (3 * 2) or (5 +3) * 2.

Until this moment we have avoided the problem simply because markup constructs surround the object on which they are applied. So there is not ambiguity in choosing which one to apply first: it’s the most external. Imagine if this expression was written as:

That would make obvious to ANTLR how to parse it.

These types of rules are called left-recursive rules. You might say: just parse whatever comes first. The problem with that is semantic: the addition comes first, but we know that multiplications have a precedence over additions. Traditionally the way to solve this problem was to create a complex cascade of specific expressions like this:

This way ANTLR would have known to search first for a number, then for multiplications and finally for additions. This is cumbersome and also counterintuitive, because the last expression is the first to be actually recognized. Luckily ANTLR4 can create a similar structure automatically, so we can use a much more natural syntax.

In practice ANTLR consider the order in which we defined the alternatives to decide the precedence. By writing the rule in this way we are telling to ANTLR that the multiplication has precedence on the addition.

29. Parsing Spreadsheets

Now we are prepared to create our last application, in C#. We are going to build  the parser of an Excel-like application. In practice, we want to manage the expressions you write in the cells of a spreadsheet.

With all the knowledge you have acquired so far everything should be clear, except for possibly three things:

  1. why the parentheses are there,
  2. what’s the stuff on the right,
  3. that thing on line 6.

The parentheses comes first because its only role is to give the user a way to override the precedence of operator, if it needs to do so. This graphical representation of the AST should make it clear.Parentheses to change the operator precedence

The things on the right are labels, they are used to make ANTLR generate specific functions for the visitor or listener. So there will be a VisitFunctionExp, a VisitPowerExp, etc. This makes possible to avoid the use of a giant visitor for the expression rule.

The expression relative to exponentiation is different because there are two possible ways to act, to group them, when you meet two sequential expressions of the same type. The first one is to execute the one on the left first and then the one on the right, the second one is the inverse: this is called associativity. Usually the one that you want to use is left-associativity,  which is the default option. Nonetheless exponentiation is right-associative, so we have to signal this to ANTLR.

Another way to look at this is: if there are two expressions of the same type, which one has the precedence: the left one or the right one? Again, an image is worth a thousand words.

Associativity of an expression

We have also support for functions, alphanumeric variables that represents cells and real numbers.

30. The Spreadsheet Project in C#

You just need to follow the C# Setup: to install a nuget package for the runtime and an ANTLR4 extension for Visual Studio. The extension will automatically generate everything whenever you build your project: parser, listener and/or visitor.

After you have done that, you can also add grammar files just by using the usual menu Add -> New Item. Do exactly that to create a grammar called Spreadsheet.g4 and put in it the grammar we have just created. Now let’s see the main Program.cs.

There is nothing to say, apart from that, of course, you have to pay attention to yet another slight variation in the naming of things: pay attention to the casing. For instance, AntlrInputStream, in the C# program, was ANTLRInputStream in the Java program.

Also you can notice that, this time, we output on the screen the result of our visitor, instead of writing the result on a file.

31. Excel is Doomed

We are going to take a look at our visitor for the Spreadsheet project.

VisitNumeric and VisitIdAtom return the actual numbers that are represented either by the literal number or the variable. In a real scenario DataRepository would contain methods to access the data in the proper cell, but in our example is just a Dictionary with some keys and numbers. The other methods actually work in the same way: they visit/call the containing expression(s). The only difference is what they do with the results.

Some perform an operation on the result, the binary operations combine two results in the proper way and finally VisitParenthesisExp just reports the result higher on the chain. Math is simple, when it’s done by a computer.

32. Testing Everything

Up until now we have only tested the parser rules, that is to say we have tested only if we have created the correct rule to parse our input. Now we are also going to test the visitor functions. This is the ideal chance because our visitor return values that we can check individually. In other occasions, for instance if your visitor prints something to the screen, you may want to rewrite the visitor to write on a stream. Then, at testing time, you can easily capture the output.

We are not going to show SpreadsheetErrorListener.cs because it’s the same as the previous one we have already seen; if you need it you can see it on the repository.

To perform unit testing on Visual Studio you need to create a specific project inside the solution. You can choose different formats, we opt for the xUnit version. To run them there is an aptly named section “TEST” on the menu bar.

The first test function is similar to the ones we have already seen; it checks that the corrects tokens are selected. On line 11 and 13 you may be surprised to see that weird token type, this happens because we didn’t explicitly created one for the ‘^’ symbol so one got automatically created for us. If you need you can see all the tokens by looking at the *.tokens file generated by ANTLR.

On line 25 we visit our test node and get the results, that we check on line 27. It’s all very simple because our visitor is simple, while unit testing should always be easy and made up of small parts it really can’t be easier than this.

The only thing to pay attention to it’s related to the format of the number, it’s not a problem here, but look at line 59, where we test the result of a whole expression. There we need to make sure that the correct format is selected, because different countries use different symbols as the decimal mark.

There are some things that depends on the cultural context

If your computer was already set to the American English Culture this wouldn’t be necessary, but to guarantee the correct testing results for everybody we have to specify it. Keep that in mind if you are testing things that are culture-dependent: such as grouping of digits, temperatures, etc.

On line 44-46 you see than when we check for the wrong function the parser actually works. That’s because indeed “logga” is syntactically valid as a function name, but it’s not semantically correct. The function “logga” doesn’t exists, so our program doesn’t know what to do with it. So when we visit it we get 0 as a result. As you recall this was our choice: since we initialize the result to 0 and we don’t have a default case in VisitFunctionExp. So if there no function the result remains 0. A possib alternative could be to throw an exception.

Final Remarks

In this section we see tips and tricks that never came up in our example, but can be useful in your programs. We suggest more resources you may find useful if you want to know more about ANTLR, both the practice and the theory, or you need to deal with the most complex problems.

33. Tips and Tricks

Let’s see a few tricks that could be useful from time to time. These were never needed in our examples, but they have been quite useful in other scenarios.

Catchall Rule

The first one is the ANY lexer rule. This is simply a rule in the following format.

This is a catchall rule that should be put at the end of your grammar. It matches any character that didn’t find its place during the parsing. So creating this rule can help you during development, when your grammar has still many holes that could cause distracting error messages. It’s even useful during production, when it acts as a canary in the mines. If it shows up in your program you know that something is wrong.

Channels

There is also something that we haven’t talked about: channels. Their use case is usually handling comments. You don’t really want to check for comments inside every of your statements or expressions, so you usually throw them way with -> skip. But there are some cases where you may want to preserve them, for instance if you are translating a program in another language. When this happens you use channels. There is already one called HIDDEN that you can use, but you can declare more of them at the top of your lexer grammar.

Rule Element Labels

There is another use of labels other than to distinguish among different cases of the same rule. They can be used to give a specific name, usually but not always of semantic value, to a common rule or parts of a rule. The format is label=rule, to be used inside another rule.

This way left and right would become fields in the ExpressionContext nodes. And instead of using context.expression(0), you could refer to the same entity using context.left.

Problematic Tokens

In many real languages some symbols are reused in different ways, some of which may lead to ambiguities. A common problematic example are the angle brackets, used both for bitshift expression and to delimit parameterized types.

The natural way of defining the bitshift operator token is as a single double angle brackets, ‘>>’. But this might lead to confusing a nested parameterized definition with the bitshift operator, for instance in the second example shown up here. While a simple way of solving the problem would be using semantic predicates, an excessive number of them would slow down the parsing phase. The solution is to avoid defining the bitshift operator token and instead using the angle brackets twice in the parser rule, so that the parser itself can choose the best candidate for every occasion.

34. Conclusions

We have learned a lot today:

  • what are a lexer and a parser
  • how to create lexer and parser rules
  • how to use ANTLR to generate parsers in Java, C#, Python and JavaScript
  • the fundamental kinds of problems you will encounter parsing and how to solve them
  • how to understand errors
  • how to test your parsers

That’s all you need to know to use ANTLR on your own. And I mean literally, you may want to know more, but now you have solid basis to explore on your own.

Where to look if you need more information about ANTLR:

Also the book it’s only place where you can find and answer to question like these:

ANTLR v4 is the result of a minor detour (twenty-five years) I took in graduate
school. I guess I’m going to have to change my motto slightly.

Why program by hand in five days what you can spend twenty-five years of your
life automating?

We worked quite hard to build the largest tutorial on ANTLR: the mega-tutorial! A post over 13.000 words long, or more than 30 pages, to try answering all your questions about ANTLR. Missing something? Contact us and let us now, we are here to help

The important changes in the new ANTLR 4.6



The important changes in the new ANTLR 4.6

After almost a year since the last major release, there is a new ANTLR version: 4.6. There are many news: new targets, better perfomance, better error handling and several improvements in the development of ANTLR itself.

New targets

The most impactful news is probably the new targets: C++, Go and Swift. Of course getting C++ support is a big deal. Hate it or love it, this is still one of the big languages out there. Go has gained traction in network applications, such as webservers and API, thanks to its great support for concurrency. This almost double the available targets and join the already included Java, C#, Python and Javascript.

Major performance improvement

One of the greatest addition in ANTLR 4 was the support for left-recursive expression, that is to say expressions that have one or more alternatives that referenced themselves. This greatly simplified grammar rules needed to support expressions, but there were were cases of nonterminating parses for very large expressions. This happened because of a problem with the parsing engine, due to an ambiguity between two choices. Both lead to a valid parse, but one was much slower than the other. The problem was discovered by Sam Harwell, one of the key contributors to ANTLR.

Error handling and messages

There have been improvements in error handling of some cases: related to LL(1) decisions, matching set of tokens mistakenly considered resynchronization tokens and the occasional non inclusion of error nodes for single token. Furthermore there are better error messages, for instance in the case of rules conflicting with symbols in the generated code in the specified target language.

Improvement in the development of ANTLR

Other important news are several improvements related to the development of ANTLR itself. While this don’t directly affect you, as a user, they may make easier for you to contribute to the project, to study how a big Java project works or even inspire you to improve your own opensource project. These range from betterment to the build system and the maven plug-in to a completely rewritten unit test mechanism. Also it’s useful to be aware that now the build environment requires ANTLR Java 7/JDK 1.7, a change spurred by the Swift target.

Conclusions

ANTLR is a precious tool for many people interested in languages. This release proves once again that ANTLR is here to stay and it keeps evolving. This release is a bit special because of the significant number of meaningful changes. I can see this projecting more enthusiasm in the ANTLR community and I am looking forward to see more great things happening in this area.

Kanvas: generating a simple IDE from your ANTLR grammar

What is an editor?

An editor is, for me, the main tool I use for work. As a Language Engineer I create new languages, I use existing ones and I need different tools to work with them. I would like to be able to hack all of them together, in a customized IDE I can grow for me. This is why I am working on Kanvas, the hackable editor. Which is on GitHub, of course.

In many cases I need a simple text editor for my DSLs and I tend to build them using ANTLR. I will need other stuff, like tabular or graphical projections, simulators and more but I need to start somewhere, right? Also, I think right now there is not an easy way to get a standalone editor for a DSL, with minimal dependencies and a simple structure. There is not a light option on the menu. Time to add one.

Getting an editor from your grammar quickly

Once you define the grammar of your language there is a lot of information you can extract from it. I think you should be able to get as much value as possible from it for free, with the possibility to customize it further, if needed. This is similar to the idea behind Xtext (minus the 400 pages you need to read to understand EMF).

How quickly can you get an editor for your ANTLR grammar? You create a new project for your editor, add Kanvas as a dependency and register which languages do you intend to support:

and add these lines to support your language:

This quickly. Less then 10 lines of code. We just need to specify the Lexer and Parser classes (SMLexer and SMParser in this example).

If you are wondering what language is that, that is Kotlin: a concise static language for the JVM, easily interoperable with Java.

Let’s improve it a little bit: syntax highlighting

So I have a simple language, I get an editor basically for free and I start using it. As first thing I want to define the style for the different kind of tokens. We are doing something simple, just setting the colors:

We are not setting certain tokens to be bold or in italic because we want to keep things simple. By the way, if you are interested in how syntax highlighting works in Kanvas, I described it in this post.

And then comes autocompletion

Now, we get some limited autocompletion for free. We basically get autocompletion depending on the structure of the language, so our algorithm can tell us which keywords can be inserted in the current position or that in a certain position an identifier can be accepted. What the algorithm cannot not determine for free is which identifiers should suggest. Let’s implement a very simple logic: when we can insert an identifier we look at the preceeding tokens and use them to determine which suggestion to make. For example, when defining an input we could suggest “anInput” while when defining a variable we could suggest “aVar”:

Here is the code. Is this enough? I do not know, but what I know is that this is a system small enough to be understandable and simple enough to be easily extended and customized. So I plan to use it for this small language, and improve the autocompletion as needed, specifically for this language. Organically and iteratively grow tool support is the name of the game.

Design goals: something similar to Sublime Text but open-source

We all love Sublime Text. I would like to have something inspired to it, but open-source. Why open-source? So that I can customize it as much as I want.

This is how it looks like for now:

Yes, it is not yet as beautiful as Sublime Text. But this means I have space for improvement.

To Language Workbench or to not Language Workbench?

I work routinely with Language Workbenches such as Jetbrains MPS and Xtext. They are great because they permit to obtain very good tool support very quickly. In many situations they are your best option. However, as every engineering choice, there are different aspects to consider. Jetbrains MPS and Xtext are very large and complex pieces of software, the kind of stuff that weight hundreds of MBs. To learn the internals of these platforms require a lot of work and a large effort. You can have a huge benefit by simply using those platforms. However they are not the best solution in all situations because in some situations you need to integrate your language with existing systems and thus you have to bend those Language Workbenches in ways they are not designed to. Maybe you want to embed your editor or tools in your existing platform, maybe you want to have a simple editor to use on a tablet, maybe you want tools to use from the command line. Maybe you want to hack a system together to fit your particular needs in some peculiar way. In those cases using a Language Workbench is not the right choice. You need something simple, something hackable. This is the approach I am experimenting it. To do that I am working on a few open-source projects and writing a book.

Conclusions

Will this fly? I do not know. I am having fun spending the few time I find on this project. And I feel it can be a good approach to get simple standalone editors for DSLs built with ANTLR. I would also like to use it as my sort of Kotlin-powered vim, a vim for the new millenium. With super-projectional-powers. Let’s see how this grows.

And yes, I know that Atom describes itself as the hackable editor. But it is not hackable enough from my point of view.

Getting started with ANTLR in C#

The code for this article is available on github.

Readers of this website will know that ANTLR is a great tool to quickly create parsers and help you in working with a known language or create your DSL. While the tool itself is written in Java it can also be used to generate parsers in several other languages, for instance Python, C# or Javascript (with more languages supported by the newly released 4.6 version).

If you want to use C# you can integrate ANTLR in your favorite IDE, as long as that IDE is any recent edition of Visual Studio. The runtime itself works also on Mono, and can be used as a standalone and you can look at the issues for the official C# target for ANTLR 4 to see if you can make it work with other setups, but the easiest way is to use Visual Studio and the provided extension to integrate the generation of the grammar into the your C# project.

Setup

The first step is to install ANTLR Language Support extension for Visual Studio, you just have to search for it in for Visual Studio going to ToolsExtensions and Updates. This will allow to easily integrate ANTLR into your workflow by generating automatically the parser and, optionally, listener and visitor starting from your grammar. Now you can add a new ANTLR 4 Combined Grammar or an ANTLR 4 Lexer/Parser in the same way you add any other new item. Then, for each one of your projects, you must add the Nuget package for Antlr4. If you want to manage options and, for instance disable the visitor/listener generation, you can see the official github project.

Create the Grammar

For our simple project we are going to create grammar that parses two lines of text that represents a chat between two people. This could be the basis for a chat program or for a game in which whoever says the shortest word get beaten up with a thesaurus. This is not relevant for the grammar itself, because it handles only the recognition of the various elements of the program. What you choose to do with these elements is managed through the normal code. Add a new ANTLR 4 Combined Grammar with the name Speak. You will see that there is already some text in the new file; delete all and replace it with the following text.

While you may create separate lexer and parser grammar, for a simple project you will want to use a combined grammar and put the parser before the lexer. That’s because as soon as antlr recognize a token in the lexer part, it stop searching. So it’s also important to put the more specific tokens first and then the generic ones, like WORD or ID later. In this example, if we had inverted SAYS and WORD, SAYS would have been hidden by WORD. Another thing to notice is that you can’t use fragments outside of lexer rules.

Having said that, the lexer part is pretty straightforward: we identify a SAYS, that could be written uppercase or lowercase, a WORD, that could be composed of any letter uppercase or lowercase and a NEWLINE. Any text that is WHITESPACE, space and tab, is simply ignored. While this is clearly a simple case, lexer rules will hardly be more complicated than this. Usually the worst thing that could happen is to have to use semantic predicates. These are essentially statement that evaluates to true or false, and in the case they are false they disable the following rule. For instance, you may want to use a ‘/’ as the beginning of a comment, only if it is the first character of a line, otherwise it should be considered an arithmetic operator.

The parser is usually where things gets more complicated, although that’s not the case this time. Every document given to a speak grammar must contain a chat, that in turn is equal to two line rules followed by a End Of File marker. The line must contain a name, the SAYS keyword and a word. Name and word are identical rules, but they have different names because they correspond to different concepts, and they could easily change in a real program.

Visiting the tree

Just like we have seen for Roslyn, ANTLR will automatically create a tree and base visitor (and/or listener). We can create our own visitor class and change what we need. Let’s see an example.

The first line shows how to create a class that inherit from the SpeakBaseVisitor class, that is automatically generated by ANTLR. If you need it, you could restrict the type, for instance for a calculator grammar you could use something like int or double. SpeakLine (not shown) is a custom class that contains two properties: Person and Text. The line 5 shows how to override the function to visit the specific type of node that you want, you just need to use the appropriate type for the context, that contains the information provided by the parser generated by ANTLR. At line 13 we return the SpeakLine object that we just created, this is unusual and it’s useful for the unit testing that we will create later. Usually you would want to return base.VisitLine(context) so that the visitor could continue its journey across the tree.

This code simply populate a list of SpeakLine that hold the name of the person and the word they have spoken. The Lines properties will be used by the main program.

Putting it all together

As you can see there is nothing particularly complicated. The lines 15-18 shows how to create the lexer and then create the tree. The subsequent lines show how to launch the visitor that you have created: you have to get the context for whichever starting rule you use, in our case chat, and the order to visit the tree from that node.

The program itself simply output the information contained in the tree. It would be trivial to modify the grammar program to allow infinite lines to be added, both the Visitor and the main Program would not need to be changed.

Unit testing

Testing is useful in all cases, but it is absolutely crucial when you are creating a grammar, to check that everything is working correctly. If you are creating a grammar for an existing language you probably want to check many working source file, but in any case you want to start with unit testing the single rules. Luckily since the creation of the Community edition of Visual Studio there is a free version of Visual Studio that including an unit testing framework. All you have to do is to create a new Test Project, add all the necessary nuget packages and add a reference to the project assembly you need to test.

There is nothing unexpected in this tests. One observation is that we can create a test to check the single line visitor or we can test the matching of the rule itself. You obviously should do both. You may wonder how the last test works, since we are trying to match a rule that doesn’t match, but we still get the correct type of context as a return value and some correct matching values. This happens because antlr is quite robust and there is only checking one rule. There are no alternatives and since it starts the correct way it is considered a match, although a partial one.

Conclusions

Integrating an ANTLR grammar in a C# project is quite easy with the provided Visual Studio extensions and nuget packages, making it the best way to quickly create parser for your DSL. No more piles of fragile RegEx(s), but don’t forget the tests.

Building a compiler for your own language: from the parse tree to the Abstract Syntax Tree

From the parse tree to the abstract syntax tree

In this post we are going to see how process and transform the information obtained from the parser. The ANTLR parser recognizes the elements present in the source code and build a parse tree. From the parse tree we will obtain the Abstract Syntax Tree which we will use to perform validation and produce compiled code.

Note that the terminology can vary: many would call the tree obtained from ANTLR an Abstract Syntax Tree. I prefer to mark the difference from this two steps. To me the parse tree is the information as meaningful to the parser, the abstract syntax tree is the information reorganized to better support the next steps.


This post is the part of a series. The goal of the series is to describe how to create a useful language and all the supporting tools.

  1. Building a lexer
  2. Building a parser
  3. Creating an editor with syntax highlighting
  4. Build an editor with autocompletion
  5. Mapping the parse tree to the abstract syntax tree
  6. Model to model transformations
  7. Validation
  8. Generating bytecode

After writing this series of posts I refined my method, expanded it, and clarified into this book titled
How to create pragmatic, lightweight languages

Code

Code is available on GitHub under the tag 05_ast

Spice up our language

In this series of post we have been working on a very simple language for expressions. It is time to make our language slightly more complex introducing:

  • casts for example: 10 as Decimal or (1 * 2.45) as Int
  • print statement for example: print(3 + 11)

To do so we need to revise our lexer and parser grammar. The syntax highlighting and autocompletion which we have built in previous posts will just keep working.

The new lexer grammar:

And the new parser grammar:

The Abstract Syntax Tree metamodel

The Abstract Syntax Tree metamodel is simply the structure of the data we want to use for our Abstract Syntax Tree (AST). In this case we are defining it by defining the classes which we will use for our AST.

The AST metamodel will look reasonably similar to the parse tree metamodel, i.e., the set of classes generated by ANTLR to contain the nodes.

There will be a few key differences:

  • it will have a simpler and nicer API than the classes generated by ANTLR (so the classes composing the parse tree). In next sections we will see how this API could permit to perform transformations on the AST
  • we will remove elements which are meaningful only while parsing but that logically are useless: for example the parenthesis expression or the line node
  • some nodes for which we have separate instances in the parse tree can correspond to a single instance in the AST. This is the case of the type references Int and Decimal which in the AST are defined using singleton objects
  • we can define common interfaces for related node types like BinaryExpression
  • to define how to parse a variable declaration we reuse the assignement rule. In the AST the two concepts are completely separated
  • certain operations have the same node type in the parse tree but are separated in the AST. This is the case of the different types of binary expressions

Let’s see how we can define our AST metamodel using Kotlin.

We start by defining Node. A Node represents every possible node of an AST and it is general. It could be reused for other languages also. All the rest is instead specific of the language (Sandy on our case). In our specific language we need three important interfaces:

  • Statement
  • Expression
  • Type

Each of these interfaces extends Node.

We then declare the two types we use in our language. They are defined as singleton objects. It means that we have just one instance of these classes.

We then have the BinaryExpression interfacewhich extends Expression. For classes implements it, one for each of the basic arithmetic expressions.

Most of the expressions have as children other nodes. A few have instead simple values. They are VarReference (which has a property varName of type String), and Intlit and DecLit (both have a property value of type String).

Finally we have the three classes implementing Statement.

Note that we are using data classes so we can get for free the hashCode, equals and toString methods. Kotlin generates for us also constructors and getters. Try to imagine how much code that would be in Java.

Mapping the parse tree to the abstract syntax tree

Let’s see how we can get the parse tree, produced by ANTLR, and map it into our AST classes.

To implement this we have taken advantage of three very useful features of Kotlin:

  • extension methods: we added the method toAst to several existing classes
  • the when construct, which is a more powerful version of switch
  • smart casts: after we check that an object has a certain class the compiler implicitly cast it to that type so that we can use the specific methods of that class

We could come up with a mechanism to derive automatically this mapping for most of the rules and just customize it where the parse tree and the AST differs. To avoid using too much reflection black magic we are not going to do that for now. If I were using Java I would just go for the reflection road to avoid having to write manually a lot of redundant and boring code. However using Kotlin this code is compact and clear.

Testing the mapping

Of course we need to test this stuff. Let’s see if the AST we get for a certain piece of code is the one we expect.

This would be all nice: we have a clean model of the information present in the code. The metamodel and the mapping code looks very simple and clear. However we would need to add a little detail: the position of the nodes in the source code. This would be needed while showing errors to the user. We want to have the possibility to specify the positions of our AST nodes but we do not want to be forced to do so. In this way depending on the operations we need to do we can ignore or not the positions. Consider the tests we have written so far: wouldn’t be cumbersome and annoying having to specify fake positions for all the nodes? I think so.

This is the new Node definition and a few supporting class:

We need also to add position as an optional parameter to all the classes. It would have the default value null. For example this is how SandyFile looks now:

The parse tree contains the information organized in the most convenient way for the parser. It is typically not the most convenient way for the steps which follow. Think about the variable declaration rule being implemented by reusing the assignment rule: sure, this make the grammar shorter and it makes sense for the parse tree. However from the logical point of view the two elements are separated, and in the AST they are indeed.

Most of the rest of our tools will operate on the AST so it is better to spend some time working on an AST that makes sense.

Building autocompletion for an editor based on ANTLR

In this post we are going to see how to build autocompletion in our editor. We will derive the items to suggest automatically from our ANTLR grammar.

kanvas_autocompletion_menu

Our editor with autocompletion

This post is the part of a series. The goal of the series is to describe how to create a useful language and all the supporting tools.

  1. Building a lexer
  2. Building a parser
  3. Creating an editor with syntax highlighting
  4. Build an editor with autocompletion
  5. Mapping the parse tree to the abstract syntax tree
  6. Model to model transformations
  7. Validation
  8. Generating bytecode

After writing this series of posts I refined my method, expanded it, and clarified into this book titled
How to create pragmatic, lightweight languages



Code

Code is available on GitHub. The code described in this post is associated to the tag autocompletion

How this will work

The main point here is that we need to understand what kind of token could follow the caret. These are the relevant interfaces:

EditorContext will describe what precedes the caret. It will basically be a list of tokens.

How can we find those tokens? By using the ANTLR lexer on all the text preceding the caret. We then take all the tokens from the channel 0 (the default channel: we are not interested in comments or whitespace) and put them in a list. Now, the last token will be the EOF token representing the end of the stream we sent to the lexer. We put instead a special token of type CARET_TOKEN_TYPE.

Now it comes the funny part: we are going to simulate the choices of our ANTLR parser and then look which tokens it would expect to keep parsing.

All the magic happen in the process function. To it we pass ruleNames and vocabulary which are just needed for debugging. We then pass the initial ATN state. ATN is an internal structure used by the ANTLR parser. It represents an automata that can change state through epsilon transitions or when a certain token is received. We will start from the initial state and process the tokens we have in front of us until we reach the special token representing the caret. At that point we will look which transitions are available in the current state. The tokens used by those transitions are the tokens the parser would expect and therefore they will be the tokens we will suggest to the user.

Note that multiple transitions are possible from some states so we will follow all possible paths. We will collect all suggestions using the collector object. At this stage we are not concern about performance issue. In practice we may want to use some form of caching.

There is another object we did not discuss: it is the ParserStack instance. It is needed to track the path followed by the automata. This is because certain transitions should be followed only if the parser arrives from a certain path. For example at the end of an expression we may want to recognize a right parenthesis to complete parsing an expression surrounded by parenthesis. However this makes sense only if we have recognized a left parenthesis before. The ParserStack  tell us that.

Let’s start by looking at the function process:

We start by checking if we have reached the caret (in that case atCaret will be true). We then pass the current state to the stack to be processed: in many cases it will just add the state at the top of the stack. However some states are used to match previously states. They sort of close some operation which was started by another state that should be on the top of the stack. If the matching state is found on top of the stack it is removed, if it is not found it means this parsing path is unsuccessful and we abort it.

If the parsing path has not been aborted we look at all the transitions leaving the current state. We just follow all the epsilon transitions (with a small caveat to avoid infinite loops: see the alreadyPassed variable). If instead we have an AtomTransition it means that the transition needs a specific token:

  • if we have not yet reached the caret we look at the next token in the stream: if it match the one required by the transition we follow it, otherwise we don’t
  • if we have reached the caret this is a potential next token, so we collect it. We just check if the state at the end of the transition is compatible with our current stack

Let’s now look at ParserStack:
