Written by Federico Tomassetti
in ANTLR, Parsing

    I like processing code for several purposes, like static analysis or automated refactoring. The interesting part to me is to reason on the models you build from the Abstract Syntax Tree (AST). To get there you need a way to get the AST from your source files. This can be done easily using ANTLR and the collection of complete grammars available here: https://github.com/antlr/grammars-v4

    antlr logo
    Antlr: a great lexer and parser generator

    Thank you folks for all the grammars!

    We are just going to take the one for Python 3, which should work fine also for Python 2. If we will need to do minor adjustment we can easily do that starting from this base.

    Getting the Grammar

    First things first: let’s get the grammar.

    Just visit https://github.com/antlr/grammars-v4 and take the grammar you need. Most grammars have a very permissive license.

    There are tens of grammars for languages such as R, Scala, Python, Swift, PHP and many others. There is also one for Java but for Java you prefer to use JavaParser, am I right?

    Just copy the grammar into your new project, under src/main/antlr

    Setting Up the Project Using Gradle

    Now we are going to setup a build script with Gradle.

    We will use the ANTLR4 plugin from melix, because I find it more flexible of the one described in the official documentation.

    We will generate the code in a specific package (me.tomassetti.pythonast.parser) and therefore in a directory derived from that package (build/generated-src/me/tomassetti/pythonast/parser).

    buildscript {
        repositories {
            maven {
                name 'JFrog OSS snapshot repo'
                url  'https://oss.jfrog.org/oss-snapshot-local/'
            }
            jcenter()
        }

        dependencies {
            classpath 'me.champeau.gradle:antlr4-gradle-plugin:0.1.1-SNAPSHOT'
        }
    }

    repositories {
        mavenCentral()
        jcenter()
    }

    apply plugin: 'java'
    apply plugin: 'me.champeau.gradle.antlr4'

    antlr4 {
        source = file('src/main/antlr')
        output = file('build/generated-src/me/tomassetti/pythonast/parser')
        extraArgs = ['-package', 'me.tomassetti.pythonast.parser']
    }

    compileJava.dependsOn antlr4

    sourceSets.main.java.srcDirs += antlr4.output

    configurations {
        compile.extendsFrom antlr4
    }

    task fatJar(type: Jar) {
        manifest {
            attributes 'Implementation-Title': 'Python-Parser',
                       'Implementation-Version': '0.0.1'
        }
        baseName = project.name + '-all'
        from { configurations.compile.collect { it.isDirectory() ? it : zipTree(it) } }
        with jar
    }


    I also added a fatJar task. That tasks produce a JAR containing all the dependencies. I use it to import the parser into Jetbrains MPS more easily.

    To generate the parser from the grammar you can just run gradle antlr4.

    You can then have to explain to your IDE that it should consider the code under build/generated-src.

    How to Invoke the Parser

    Now let’s see how we can invoke the parser.

    public class ParserFacade {

        private static String readFile(File file, Charset encoding) throws IOException {
            byte[] encoded = Files.readAllBytes(file.toPath());
            return new String(encoded, encoding);
        }

        public Python3Parser.File_inputContext parse(File file) throws IOException {
            String code = readFile(file, Charset.forName("UTF-8"));
            Python3Lexer lexer = new Python3Lexer(new ANTLRInputStream(code));
            CommonTokenStream tokens = new CommonTokenStream(lexer);
            Python3Parser parser = new Python3Parser(tokens);
            return parser.file_input();
        }
    }

    Our ParserFacade has just one public method named parse. It gets a File and it returns an AST. It could hardly be simpler than that.

    Let’s Look at Some ASTs

    Let’s take a simple file:

    def sum(a, b):
        return a + b

    print("The sum of %i and %i is %i" % (5, 3, sum(5, 3)))

    And now get the AST. We can print it using this code:

    public class AstPrinter {

        public void print(RuleContext ctx) {
            explore(ctx, 0);
        }

        private void explore(RuleContext ctx, int indentation) {
            String ruleName = Python3Parser.ruleNames[ctx.getRuleIndex()];
            for (int i=0;i<indentation;i++) {
                System.out.print("  ");
            }
            System.out.println(ruleName);
            for (int i=0;i<ctx.getChildCount();i++) {
                ParseTree element = ctx.getChild(i);
                if (element instanceof RuleContext) {
                    explore((RuleContext)element, indentation + 1);
                }
            }
        }

    }

    If we parse the simple example and print it with AstPrinter we get a super complex AST. The first lines look like:

    file_input
      stmt
        compound_stmt
          funcdef
            parameters
              typedargslist
                tfpdef
                tfpdef
            suite
              stmt
                simple_stmt
                  small_stmt
                    flow_stmt
                      return_stmt
                        testlist
                          ...

    For the way the parser it is build there are a lot of annidated rules. That makes sense while parsing but it produces a very polluted AST. I think there are two different ASTS: as a parsing AST which is easy to produce, and a logic AST that it is easy to reason about. Luckily we can transform the first one in the latter without too much effort.

    One simple way is to list all the rules that are just wrappers and skip them, taking their only child instead. We could have to refine this but as a first approximation let’s just skip the nodes which have just one children which is another parser rule (no terminals).

    In this way we go from 164 nodes to 28. The resulting logic AST is:

    file_input
      funcdef
        parameters
          typedargslist
            tfpdef
            tfpdef
        suite
          simple_stmt
            return_stmt
              arith_expr
                atom
                atom
      simple_stmt
        power
          atom
          trailer
            term
              string
              atom
                testlist_comp
                  integer
                  integer
                  power
                    atom
                    trailer
                      arglist
                        integer
                        integer

    In this tree everything should we mapped to a concept we understand, with no artificial nodes in the way, nodes just created for parsing reasons.

    Conclusions

    Writing parsers is no where we can produce most value. We can easily reusing existing grammars, generate parsers and build our smart applications using those parsers.

    There are several parser-generators out there and most of them are good enough for most goals you can have. Among them I tend to use ANTLR more than others: it is mature, it is supported, it is fast. The ASTs it produces can be navigated both using hereogeneous APIs (we have single classes genered for each kind of node) and homogeneous APIs (we can ask to each node which rule it represents and the list of its children).

    Another great benefit of ANTLR is the presence of grammars ready to be used. Building grammars require experience and some work. Especially for complex GPL like Java or Python. It also requires very extensive testing. We are still finding minor issues with the Java 8 grammars behind JavaParser even if we have parsed literally hundreds of thousands of files using it. This is a very good reason to not write your own grammar if you can avoid that.

    By the way, all the code is available on github: python-ast.
